Functions:
Heating & DHW. Fully integrated wall-hung unit (60L/80L/100L). Factory pre-charged with refrigerant; no on-site refrigerant work required. Simply fix to a solid wall and connect water pipes, drastically reducing renovation time and labor costs.Trusted China source factory. OEM/ODM bulk orders & customization available.
Certifications:
CE · ErP
• Horizontal/Vertical optiona
• Maximum outlet water temperature up to 75°c
• Multiple running mode
• Silent running, low to 38dBA
• 4-way valve auto-defrosting, down to -7°C
• Enamel inner tank, long service life
• External condenser coil, safe & reliable
• Sterilization & high-pressure protection
• R134a/R290 dual-refrigerant options
• MODBUS communication for smart building integration
• OEM/ODM available & 100% factory tested
Presenting the Micoe Wall-mounted all-in -one heat pump temp. 75 sky source heat pump water heater air to water heat pump factory.
This product that is revolutionary 3 heat that is important pump features in a solitary little style: environment deal temperature level degree pump, water warming product, as well as atmosphere towards spray temperature level degree pump. This system is perfect for domiciles as well as business preferring exceptional home heating as well as energy efficiency through possessing really a cozy production of 75 levels.
The Micoe Wall-Mounted All-In-One Heat Pump is factory-tested for enhanced dependability as well as efficiency. The smooth, wall-mounted style creates the practically every one of area as well as reduces setup opportunity. The items are fantastic for homes, condominiums, or even homes along with restricted area.
The atmosphere deal heat level pump work enables easy as well as home heating that is east’s effective winter season opportunity. This method pumps temperature level degree with among one of the absolute most truly efficient in the direction of your house, offering heated up sky throughout. The atmospheres source temperature level degree pump may be a choice that is eco-friendly ancient home heating, decreasing your carbon dioxide impact while offering incredible home heating abilities. Cozy water home heating system work is fantastic for offering towards cozy water with your home.
The Micoe Wall-Mounted All-In-One Heat Pump could be used each for downpours as well as sinks, providing a continuous method towards have cozy water without dealing with place that is additional. The atmospheres towards water heat level pump work likewise can easily recuperate temperature level degree coming from squander spray, enhancing efficiency as well as decreasing energy sets you back.
Micoe is really a dependable as well as label brand this is dependable right in to the temperature level degree level pump market. Their products or even services are notable along with their dependability, energy efficiency, as well as resilience. The Micoe Wall-Mounted All-In-One Heat Pump is none exemption. This product stayed in reality created towards final as well as is offered possessing really an ensure that is significant.
The Micoe Wall-mounted all-in -one heat pump temp. 75 sky source heat pump water heater air to water heat pump factory is a game-changer in the home heating market. Its own smooth as well as effective style, integrated along with the 3 important features, create it the ideal option for any type of house or even company looking for ideal power effectiveness as well as home heating. The Micoe brand name stands for high top premium as well as quality, creating this system the perfect financial assets for any type of home.
Micoe Group (A-share listed on the Shanghai Stock Exchange, Stock Code: 603366) is a strategic partner of the China Aerospace Program. We are proud to hold both a "National Recognized Enterprise Technology Center" and a "CNAS National Accredited Laboratory."
With state-of-the-art manufacturing bases located in Jiangsu and Guangdong, our annual production capacity for heat pumps exceeds 1 million units. Our products are fully certified under international quality systems, including CE, RoHS, ERP, ISO9001, and ISO14001.
For our export business, we are committed to providing:
Warranty: 2-year comprehensive machine warranty and a 3-year core compressor warranty.
After-Sales Support: Global 24-hour online after-sales response.
Packaging: Fumigation-free export wooden crates ensuring safe transit.
Lead Time: Stable delivery schedules, with standard bulk orders shipped within 15 to 35 days.
Are you an apartment developer, HVAC contractor, or looking for a wall-mounted solution with zero compliance risks and instant installation?
The Micoe R134a Vertical Wall-Mounted All-in-One is the smart choice to expand your product line.
Click to inquire now! Please let us know your target market, estimated quantity, and tank capacity requirements. Our technical sales team will provide you with detailed quotations, complete parameter manuals, and successful apartment renovation case studies.
We warmly welcome OEM and wholesale cooperation inquiries.
| Wall mounted all in one heat pump | |||||||||
| Model | MAHP-60C1 | MAHP-80C1 | MAHP-100C1 | MAHP-60D1 | MAHP-80D1 | MAHP-100D1 | MAHP-80G1 | MAHP-100G1 | |
| Tank Capacity (L) | 60 | 80 | 100 | 60 | 80 | 100 | 80 | 100 | |
| Refrigerant | R134a | R290 | |||||||
| Power Supply | 220-240V/50Hz | ||||||||
| Heating Capacity at Air 20℃/15℃,Water Temperature from 15℃ to 55℃ | |||||||||
| COP(W/W) | 3.55 | 3.55 | 3.55 | 3.55 | 3.55 | 3.55 | 4.32 | 4.32 | |
| Rated Heating Capacity (W) | 600 | 600 | 600 | 600 | 600 | 600 | 950 | 950 | |
| Max input power (W) | 2500 | 2500 | 2500 | 2500 | 2500 | 2500 | 2300 | 2300 | |
| Max input current (A) | 11.4 | 11.4 | 11.4 | 11.4 | 11.4 | 11.4 | 10.2 | 10.2 | |
| Heat Pump | Rated Power (W) | 169 | 169 | 169 | 169 | 169 | 169 | 220 | 220 |
| Rated Current (A) | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 | 0.98 | 0.98 | |
| Electric Heater | Rated Power (W) | 2000 | 2000 | 2000 | 2000 | 2000 | 2000 | 2000 | 2000 |
| Rated Current (A) | 9.3 | 9.3 | 9.3 | 9.3 | 9.3 | 9.3 | 10.2 | 10.2 | |
| Compressor | Highly | Highly | Highly | Highly | Highly | Highly | Highly | Highly | |
| Working temperature range ( ℃) | -7~43 | -7~43 | -7~43 | -7~43 | -7~43 | -7~43 | -7~43 | -7~43 | |
| Max allowable pressure (Mpa) | 3 | 3 | 3 | 3 | 3 | 3 | 3 | 3 | |
| Max working pressure of exhaust side (Mpa) | 3 | 3 | 3 | 3 | 3 | 3 | 3 | 3 | |
| Max working pressure of suction side (Mpa) | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 | |
| Net Weight (kg) | 39 | 42 | 50 | 39 | 42 | 45 | 48 | 56 | |
| Noise (dBA) | 43 | 46 | 54 | 43 | 46 | 49 | 48 | 48 | |
| Net Dimension (mm) | 890*480*500 | 1040*480*500 | 1180*480*500 | 480*500*977 | 480*500*1142 | 480*500*1180 | φ468*1222 | φ468*1442 | |
| Packed Dimension (mm) | 960*565*570 | 1100*565*570 | 1250*565*570 | 565*585*1010 | 565*585*1180 | 565*570*1250 | 493*498*1222 | 493*498*1442 | |
| Loading QTY(20GP/40HC) | 72/144 | 60/126 | 51/111 | 80/168 | 80/168 | 80/168 | 80/168 | 80/168 | |
🧱 European Apartments & Compact Homes (Bathroom/Kitchen Corners): The narrow vertical design fits neatly beside existing pipework, utilizing vertical space while maintaining a clean aesthetic.
🧺 Laundry Rooms & Balcony Pipe Sides: Easily shares wall space with washing machines or sinks, making water and power connections extremely straightforward.
🔄 Retrofitting Old Electric Water Heaters in Residential Communities: Designed as a direct, drop-in replacement for existing wall-mounted electric heaters (simply verify left/right water outlet orientation before installation).
🏠 High-End Studio Apartments & Micro-Homes: The 100L capacity fully meets the daily hot water needs of 1-2 occupants, providing a space-saving and energy-efficient upgrade.
Q1: What is the difference between this Vertical unit and your previous Horizontal model?
A1: The primary difference lies in the shape and how they utilize space. The Horizontal model is shorter and wider, occupying horizontal space. This Vertical model, however, features a narrow, tall profile that maximizes vertical wall space. It is specifically designed for mounting on long, narrow walls. Additionally, the water pipe connections for this vertical unit are designed as a right-side outlet.
Q2: The 100L vertical unit only weighs 50kg. Is it safe to mount on the wall?
A2: Absolutely safe. 50kg is quite lightweight for standard brick or load-bearing walls. It can be securely installed using high-quality stainless steel expansion bolts by a licensed plumber, without causing any damage to the wall structure.
Q3: What are the advantages of R134a refrigerant compared to the more popular R290?
A3: R290 is indeed more eco-friendly in terms of GWP, but it is highly flammable and subject to strict shipping and indoor installation regulations. Our R134a refrigerant is completely non-flammable. This allows you to easily ship the unit to any country and safely install it in confined indoor spaces like balconies or small utility rooms, completely eliminating the compliance headaches associated with export and after-sales service for flammable refrigerants.
Q4: Can this unit provide "instant" hot water like a traditional electric water heater?
A4: As a heat pump water heater, it relies on an internal storage tank. The system rapidly heats the water to 75°C, ensuring hot water flows out immediately when you turn on the shower. While it requires a brief heating period in advance, the built-in 2000W electric booster makes the overall heating speed much faster than standard heat pumps, while maintaining high energy efficiency.
